Small 360 Derek's Dalek MiniTree
Description:
Based on Derekbackus' design of his MiniTree made of steel, we have adapted his design to a cost effective coro version.
Features:
The Small Version of Derek's Dalek MiniTree uses 10 panels with 7 Pixels/RGB nodes for a total of 70 nodes in a 360 configuration. You can install as many or as few nodes as you like. The tree also includes our 9" 20 node star that is held in place with two nodes.
- 10x7 MegaTree node configuration
- 70 Nodes total includes 9" 20 node star
- Available in Black and White
- Made from 4mm fluted plastic (coro) black or white (choose color) if no color chosen white will be selected.
- Mini tree is 14" tall without star and 22" tall with star mounted
- The base is 11" wide and the top is 3" wide
- At the base of each panel, an 1/8" hole is provides to insert a stake to anchor the tree if needed
- 100% American Made from Material, Design, and Fabrication
Assembly:
The inside of the tree has the score marks for folding. Install pixels or RGB nodes of your choice. Take the star and install the metal reinforcement rod if it isn't already installed, make sure it is in a channel that doesn't obstruct a node mounting hole. Then bend the star mounting tab slightly just below the star to make it straight when the tree is complete and it keeps the reinforcement from falling out. Make all wire connections now. When you are ready to close the tree, install the zipties loosely until you have them all in place then you can tighten them up to make the tree close.
