PhoenixRay Moving Head – Single Unit or Two-Pack

Experience the brilliance and precision of the PhoenixRay Moving Head from Mattos Designs, now available in single units and two-pack options. Designed for both professional stage lighting and home displays, this versatile lighting solution combines cutting-edge technology with unparalleled durability to create unforgettable experiences.

Key Features

  • SIRIUS HRI 230W Lamp: Produces an impressive 8000K color temperature for intense, vibrant illumination.
  • Fast and Precise Movement: Superfast drives provide a 540° X rotation in 2.1 seconds and 220° Y tilt in 1.5 seconds, with magnetic error-correcting technology for perfect positioning.
  • Dynamic Effects:
    • 17+open color wheel
    • 17 fixed gobos and 80+ moving patterns
    • 8+16 prism effects
    • Linear dimming, rainbow mirrors, and multiple strobe options
  • Multiple Operating Modes: Choose from DMX512, Sound, Auto 1, Auto 2, and Auto 3 for flexible setups and pre-programmed light shows.
  • Weatherproof Design: IP66-rated housing ensures performance in any environment, indoors or outdoors.

Specifications

Feature Details
Voltage AC100-240V, 50-60Hz
Power Consumption 350W maximum
Light Source 230W Mercury Vapor Lamp (8000K)
Patterns 17 fixed + 80 moving patterns
Color Wheel 13 colors + white
Beam Angle 1.6 degrees
XY Positioning Magnetic coded error correction
Horizontal Range 540° rotation
Vertical Range 270° tilt
DMX Channels 14
Strobe 1-25Hz, random pulse
Dimming 0-100% linear dimming
Cooling Variable speed cooling fans
Ingress Protection Rating IP66
Warranty 30 months or 4,500 hours

Available Options

Single Unit:

  • Perfect for expanding existing setups or smaller venues.

Two-Pack (With Flight Case):

  • Ideal for larger events or professional productions.

Why Choose the PhoenixRay?

  • Exceptional Brightness: The 230W mercury vapor lamp ensures unmatched illumination, ideal for professional and home applications.
  • Durable and Weatherproof: Built with IP66-rated housing for consistent performance, rain or shine.
  • Flexible and Versatile: Features advanced effects and multiple operation modes to adapt to any environment or theme.
  • Proven Reliability: Backed by a 30-month warranty and CE certification for your peace of mind.



Phoenix Ray Moving Head – High-Performance 230W Mercury Vapor Lamp Stage Lighting Pre-Sale Now Open!

$639.00 $2,198.00
Pre-Order
Options

What This Is For

DMX gear is the next level — moving heads, fountains, fog, strobes — all triggered in sync with your pixel sequences. Adds cinematic motion and effects you simply can't get from static pixels alone.

JR Recommends

Even one moving head changes how a yard reads at night. If you've outgrown static-only shows, this is the upgrade.

— JR
View details
