EVO 12mm Pixels by Mattos Designs | 12V WS2811 | Ultra-Efficient | Ships Now

The EVO Pixel exists because we got tired of fixing the same problems every season.

These aren’t just another 12mm pixel — they’re a patent-pending, native 12-volt design built to reduce failure points, cut power draw, and make installs lighter, cleaner, and more reliable.

And yes — this pre-sale ships now.

At the heart of EVO is a true 12V WS2811 chip/LED combo. No resistors. No regulators. No extra junk inside the pixel waiting to fail. Fewer components means fewer problems — and way better efficiency.

Power-wise, this is where EVO really separates itself:
Twelve EVO pixels use the same power as two standard 12V bullet pixels.
That means longer runs, fewer injections, and less power planning gymnastics — especially once you’re over 250 pixels and power balancing kicks in.

Physically, EVOs are built like tanks.
The board and wire assembly are fully epoxy-coated, then over-molded into a PVC shell. That’s two sealed layers protecting the pixel. The LED package is UL listed, and the full pixel string carries its own UL certification.

Install-wise? EVOs just make sense.
They sit flush in 10mm coro, have locking nubs so they don’t pop out mid-season, and the slightly tapered 12mm body with a flat back makes pushing thousands of pixels way less miserable.

They’re also lighter — a lot lighter.
A 1,000-pixel high-density prop built with EVOs weighs over 11 pounds less than the same prop built with standard bullet pixels.

Same brightness. Less power. Less weight. Less stress.

We’re literally field-testing these every season — and EVO keeps earning its spot.

We can handle it. We’re professionals.

📦 Box Sizes (Ships Now)

EVO Pixels are sold in bulk boxes, ready to roll:

• 500 count

• 1,000 count

• 4,000 count

• 5,000 count

• 10,000 count

Perfect for full-yard builds, MegaTrees, and commercial-scale installs.

⚙️ Specifications

• Voltage: Native 12V DC (no resistors or regulators)

• Protocol: WS2811 compliant

• Pixel Size: 12mm

• Spacing Options:

  • 4” spacing

  • 2.25” spacing

• Current Draw: ~8mA per pixel

• Protection: IP67

• Construction: Encapsulated PCB + wire, over-molded PVC shell

• Connectors: xConnect pigtails

• Wire: 10-strand black wire (standard)

• Certifications: UL Listed, CE, RoHS, FCC

• Warranty: 3-Year warranty (unmodified, uncut strings)

🔧 Why EVO Pixels

• Native 12V efficiency → fewer injections

• Constant current design → consistent color & brightness

• Double-sealed construction → fewer weather failures

• Flush coro fit → cleaner props

• Lighter builds → easier installs and takedowns

• Designed by installers, not marketers

This isn’t an “upgrade” because it sounds cool.
It’s an upgrade because it fixes real problems.
